SLW-112-01-F-D
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 24 POS 2.54mm Solder ST Thru-Hole
PDF
/
Buying Options
Total Price: USD $3.59
Unit Price: USD $3.594817
≥1 USD $3.594817
≥10 USD $3.391339
≥100 USD $3.19937
≥500 USD $3.018275
≥1000 USD $2.847436
Inventory: 8877
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Polyester, Glass Filled
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Series SLW
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 24
Number of Rows 2
Gender Female
Voltage - Rated 406VAC
Additional Feature LOW PROFILE
HTS Code 8536.69.40.40
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Forked
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 5.5A per Contact
Orientation Vertical
Insulation Height 0.180 4.57mm
Style Board to Board
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL, CSA
Voltage - Rated AC 550V
Reliability COMMERCIAL
Row Spacing - Mating 0.100 (2.54mm)
Contact Length - Post 0.115 2.92mm
Number Of PCB Rows 2
Contact Finish - Post Tin
PCB Contact Pattern RECTANGULAR
Body Depth 0.18 inch
Contact Resistance 10mOhm
Mating Contact Pitch 0.1 inch
Dimensions
Plating Thickness FLASH inch
Contact Finish Thickness - Mating 3.00μin 0.076μm
Length - Termination 0.115 inch
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
