SFMH-109-02-L-D-LC-TR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 18 POS 0.64mm Solder ST SMD T/R
PDF
/
Inventory: 4143
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material PHOSPHOR BRONZE
Contact Plating Gold
Mounting Type BOARD
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Mounting Option 1 LOCKING
Mounting Style RIGHT ANGLE
Board Mounting Option SPLIT BOARD LOCK
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type BOARD CONNECTOR
Number of Rows 2
Gender Female
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating AU ON NI
Pitch 640μm
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 0.565 inch
Number Of PCB Rows 1
Number of Contacts 18
PCB Contact Pattern RECTANGULAR
Body Breadth 0.135 inch
Contact Style SQ PIN-SKT
Contact Resistance 15mOhm
Polarization Key POLARIZED HOUSING
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.05 inch
Insulator Color BLACK
Dimensions
Plating Thickness 10μin
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
