SFM-145-T2-L-S-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RCPT 45POS 0.05 GOLD SMD
PDF
/
Inventory: 975
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Stack Height (Mating) 6.15mm 6.30mm 7.92mm 8.08mm 9.70mm 9.86mm 11.61mm 11.76mm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Technical
Insertion Force-Max .556 N
Polarization Key POLARIZED HOUSING
Mating Contact Pitch 0.05 inch
Body Breadth 0.095 inch
PCB Contact Pattern STAGGERED
Contact Finish - Post Tin
Number Of PCB Rows 2
Body Length or Diameter 2.375 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.050 1.27mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.185 4.70mm
Total Number of Contacts 45
Current Rating (Amps) 3.2A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Additional Feature TIGER EYE SYSTEM, E.L.P.
Voltage - Rated 250VAC
Number of Rows 1
Number of Positions 45
Connector Type Receptacle
Termination Solder
Part Status Active
Feature Board Guide
JESD-609 Code e3
Series Tiger Eye? SFM
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Board Mounting Option POSITIONING PIN
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
