SFM-135-02-L-S-LC-K
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
ROHS COMPLIANT Rectangular Connector Female Socket
PDF
/
Inventory: 8168
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Surface Mount
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Board Mounting Option SPLIT BOARD LOCK
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series Tiger Eye? SFM
JESD-609 Code e3
Feature Board Lock, Pick and Place
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 35
Number of Rows 1
Voltage - Rated 250VAC
Additional Feature ROHS COMPLIANT
HTS Code 8536.69.40.40
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
Contact Type Female Socket
Current Rating (Amps) 3.2A per Contact
Total Number of Contacts 35
Terminal Pitch 2.54mm
Insulation Height 0.185 4.70mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.050 1.27mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 2
Contact Finish - Post Tin
PCB Contact Pattern STAGGERED
Body Breadth 0.095 inch
Mating Contact Pitch 0.05 inch
Polarization Key POLARIZED HOUSING
Insertion Force-Max .695 N
Withdrawl Force-Min .556 N
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Stack Height (Mating) 6.15mm 6.30mm 7.92mm 8.08mm 9.70mm 9.86mm 11.61mm 11.76mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
