SFM-120-01-L-D-LC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
SAMTEC SFM-120-01-L-D-LC Wire-To-Board Connector, SFM Series, 40 Contacts, Receptacle, 1.27 mm, Through Hole, 2 Rows
PDF
/
Buying Options
Total Price: USD $9.64
Unit Price: USD $9.635677
≥1 USD $9.635677
≥10 USD $9.090258
≥100 USD $8.57571
≥500 USD $8.090301
≥1000 USD $7.632353
Inventory: 1927
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Beryllium Copper
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series Tiger Eye? SFM
JESD-609 Code e3
Feature Board Lock
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 40
Number of Rows 2
Voltage - Rated 250VAC
Additional Feature TIGER EYE CONTACT
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 3.2A per Contact
Insulation Height 0.180 4.57mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.050 1.27mm
Insulation Color Black
Number of Conductors ONE
Reliability COMMERCIAL
Body Length or Diameter 1.155 inch
Row Spacing - Mating 0.050 (1.27mm)
Contact Length - Post 0.120 3.05mm
Number Of PCB Rows 2
Contact Finish - Post Tin
PCB Contact Pattern RECTANGULAR
Body Breadth 0.145 inch
Body Depth 0.18 inch
Mating Contact Pitch 0.05 inch
Dimensions
Plating Thickness 10μin
Contact Finish Thickness - Mating 10.0μin 0.25μm
Stack Height (Mating) 6.02mm 6.17mm 7.80mm 7.95mm 9.58mm 9.73mm 11.48mm 11.63mm
Compliance
Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
