SFM-115-01-S-D-LC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
SAMTEC SFM-115-01-S-D-LC Wire-To-Board Connector, SFM Series, 30 Contacts, Receptacle, 1.27 mm, Through Hole, 2 Rows
PDF
/
Buying Options
Total Price: USD $4.85
Unit Price: USD $4.8488
≥1 USD $4.8488
≥10 USD $4.356
≥100 USD $3.9336
≥500 USD $3.5552
≥1000 USD $3.212
≥3000 USD $3.157
Inventory: 242
Minimum: 1
-
+
Technical Details
Dimensions
Contact Finish Thickness - Mating 30.0μin 0.76μm
Stack Height (Mating) 6.02mm 6.17mm 7.80mm 7.95mm 9.58mm 9.73mm 11.48mm 11.63mm
Length 22.99mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Technical
Insertion Force-Max .695 N
Max Current Rating 5A
Max Voltage Rating (AC) 250V
Mating Contact Pitch 0.05 inch
Contact Resistance 15mOhm
Housing Color Black
Contact Finish - Post Tin
Contact Length - Post 0.120 3.05mm
Row Spacing - Mating 0.050 (1.27mm)
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Pitch - Mating 0.050 1.27mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.180 4.57mm
Depth 3.68mm
Orientation Straight
Current Rating (Amps) 3.2A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Additional Feature TIGER EYE CONTACT
Voltage - Rated 250VAC
Number of Rows 2
Number of Positions 30
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock
JESD-609 Code e3
Series Tiger Eye? SFM
Published 2006
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 3 Weeks
