SFM-107-02-L-D-LC-P-TR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Tiger Eye? SFM ROHS3Compliant COMMERCIAL UL Connector Receptacle .695N 15mOhm -55C~125C 3.2A per Contact
PDF
/
Inventory: 7904
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 3.2A per Contact
Total Number of Contacts 14
Insulation Height 0.185 4.70mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.050 1.27mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Additional Feature TIGER EYE CONTACT
Voltage - Rated 250VAC
Gender Female
Number of Rows 2
Number of Positions 14
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Part Status Active
Feature Board Lock, Pick and Place
JESD-609 Code e3
Series Tiger Eye? SFM
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Withdrawl Force-Min .556 N
Insertion Force-Max .695 N
Polarization Key POLARIZED HOUSING
Mating Contact Pitch 0.05 inch
Contact Resistance 15mOhm
Body Depth 0.185 inch
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number Of PCB Rows 2
Row Spacing - Mating 0.050 (1.27mm)
Body Length or Diameter 0.505 inch
Physical
Board Mounting Option SPLIT BOARD LOCK
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 3 Weeks
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Stack Height (Mating) 6.15mm 6.30mm 7.92mm 8.08mm 9.70mm 9.86mm 11.61mm 11.76mm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Plating Thickness 10μin
