SFM-104-02-L-S-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
TIGER EYE SYSTEM E.L.P. Rectangular Connector Female Socket
PDF
/
Inventory: 6489
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Surface Mount
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Board Mounting Option PEG
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series Tiger Eye? SFM
JESD-609 Code e3
Feature Board Guide
Part Status Active
Termination Solder
Connector Type Receptacle
Number of Positions 4
Number of Rows 1
Voltage - Rated 250VAC
Additional Feature TIGER EYE SYSTEM, E.L.P.
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 3.2A per Contact
Total Number of Contacts 4
Insulation Height 0.185 4.70mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.050 1.27mm
Insulation Color Black
Number of Conductors ONE
Reliability COMMERCIAL
Body Length or Diameter 0.325 inch
Number Of PCB Rows 2
Contact Finish - Post Tin
PCB Contact Pattern STAGGERED
Body Breadth 0.095 inch
Mating Contact Pitch 0.05 inch
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Stack Height (Mating) 6.15mm 6.30mm 7.92mm 8.08mm 9.70mm 9.86mm 11.61mm 11.76mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
