SFM-102-02-S-S-A-K

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description STAGGERED CONFIGURATION Rectangular Connector Female Socket
PDF
/
Inventory: 10018
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Stack Height (Mating) 6.15mm 6.30mm 7.92mm 8.08mm 9.70mm 9.86mm 11.61mm 11.76mm
Contact Finish Thickness - Mating 30.0μin 0.76μm

Technical

Contact Finish - Post Tin
Insulation Color Black
Pitch - Mating 0.050 1.27mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.185 4.70mm
Total Number of Contacts 2
Current Rating (Amps) 3.2A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
Additional Feature STAGGERED CONFIGURATION
Voltage - Rated 250VAC
Number of Rows 1
Number of Positions 2
Connector Type Receptacle
Termination Solder
Part Status Active
Feature Board Guide, Pick and Place
Series Tiger Eye? SFM
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Contact Material Beryllium Copper

Supply Chain

Factory Lead Time 3 Weeks
