SFC-140-T1-FM-D-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 80 POS 1.27mm Solder ST Thru-Hole
PDF
/
Inventory: 4701
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 3.00??in 0.076??m
Plating Thickness 3??in
Technical
Withdrawl Force-Min .556 N
Insertion Force-Max .695 N
Polarization Key LEFT
Mating Contact Pitch 0.05 inch
Contact Resistance 15mOhm
Body Depth 0.18 inch
Body Breadth 0.145 inch
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number Of PCB Rows 2
Contact Length - Post 0.120 3.05mm
Row Spacing - Mating 0.050 (1.27mm)
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.050 1.27mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.180 4.57mm
Current Rating (Amps) 3.1A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Voltage - Rated 350VAC
Gender Female
Number of Rows 2
Number of Positions 80
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
Feature Board Guide
JESD-609 Code e3
Series Tiger Eyea?? SFC
Packaging Tube
Operating Temperature -55?°C~125?°C
Physical
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
