RSM-116-02-L-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 16 POS 1.27mm Solder ST SMD Tube
PDF
/
Buying Options
Total Price: USD $3.17
Unit Price: USD $3.168
≥1 USD $3.168
≥10 USD $2.86
≥100 USD $2.6576
≥500 USD $2.5344
≥1000 USD $2.349987
Inventory: 89
Minimum: 1
-
+
Technical Details
Technical
Part Status Active
Termination Solder
Connector Type Receptacle
Number of Positions 16
Number of Rows 1
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 3.1A per Contact
Total Number of Contacts 16
Orientation Straight
Depth 2.54mm
Insulation Height 0.240 6.10mm
Style Board to Board
Number of Positions Loaded All
Pitch - Mating 0.050 1.27mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Contact Finish - Post Tin
Contact Resistance 10mOhm
Mating Contact Pitch 0.05 inch
Insertion Force-Max .973 N
Pbfree Code yes
JESD-609 Code e3
Series RSM
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C
Dimensions
Length 20.57mm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Physical
Mounting Option 1 LOCKING
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
Compliance
Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
