MMS-139-01-L-DH
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
SAMTEC MMS-139-01-L-DH Board-To-Board Connector, Horizontal, MMS Series, 78 Contacts, Receptacle, 2 mm, Through Hole
PDF
/
Inventory: 2606
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole, Right Angle
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Housing Material Plastic
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 2000
Series MMS
JESD-609 Code e3
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 78
Number of Rows 2
Additional Feature MOUNT, HORIZ
HTS Code 8536.69.40.40
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 3.9A per Contact
Insulation Height 0.157 4.00mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.079 2.00mm
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Row Spacing - Mating 0.079 (2.00mm)
Contact Length - Post 0.120 3.05mm
Number Of PCB Rows 2
Lead Pitch 2mm
Contact Finish - Post Tin
Body Breadth 0.157 inch
Housing Color Black
Body Depth 0.175 inch
Contact Resistance 10mOhm
Mating Contact Pitch 0.079 inch
Polarization Key POLARIZED HOUSING
PCB Contact Row Spacing 4.699 mm
Withdrawl Force-Min .6116 N
Dimensions
Height 4mm
Length 78mm
Width 4.45mm
Plating Thickness 10μin
Contact Finish Thickness - Mating 10.0μin 0.25μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
