MMS-112-01-T-SV

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description TOP ENTRY; BOTTOM ENTRY Rectangular Connector Header
PDF
/
Buying Options
Total Price: USD $2.8
Unit Price: USD $2.7984
≥1 USD $2.7984
≥10 USD $2.5432
≥100 USD $2.24092
≥500 USD $1.904813
≥1000 USD $1.624691
≥3000 USD $1.477555
Inventory: 428
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Width 2mm
Length 24.56mm

Technical

Contact Resistance 10mOhm
Housing Color Black
Lead Pitch 2mm
Contact Length - Post 0.115 2.92mm
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.175 4.45mm
Depth 2mm
Orientation Straight
Current Rating (Amps) 3.9A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Tin
Fastening Type Push-Pull
Additional Feature TOP ENTRY; BOTTOM ENTRY
Gender Female
Number of Rows 1
Number of Positions 12
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series MMS
Published 2000
Packaging Tube
Operating Temperature -55°C~105°C

Physical

Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
