MMS-110-02-F-DH-TR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Female Socket
PDF
/
Inventory: 8144
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Shape Square
Mounting Type Surface Mount, Right Angle
Contact Material Phosphor Bronze
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Supply Chain
Factory Lead Time 2 Weeks
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 3.00μin 0.076μm
Length 20.56mm
Technical
Contact Resistance 10mOhm
Contact Finish - Post Tin
Row Spacing - Mating 0.079 (2.00mm)
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.157 4.00mm
Depth 4.5mm
Orientation Right Angle
Current Rating (Amps) 3.9A per Contact
Contact Type Female Socket
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Female
Number of Rows 2
Number of Positions 20
Connector Type Receptacle
Termination Solder
Part Status Active
Pbfree Code yes
Series MMS
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
