HLE-125-02-SM-DV-BE-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 50 POS 2.54mm Solder ST SMD Tube
PDF
/
Inventory: 6646
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Surface Mount
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Housing Material Polymer
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 2016
Series HLE
JESD-609 Code e3
Feature Board Guide
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Bottom Entry
Number of Positions 50
Number of Rows 2
Gender Female
Voltage - Rated 400VAC
Additional Feature BOTTOM ENTRY, TIGER BEAM CONTACT
Fastening Type Push-Pull
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 4.1A per Contact
Total Number of Contacts 50
Orientation Straight
Depth 5.08mm
Insulation Height 0.144 3.66mm
Style Board to Board
Number of Positions Loaded All
Reach Compliance Code not_compliant
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Row Spacing - Mating 0.100 (2.54mm)
Contact Finish - Post Tin
Max Voltage Rating (AC) 400V
Dimensions
Length 63.5mm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Compliance
RoHS Status ROHS3 Compliant
