FOLC-130-L1-L-Q-LC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RCPT 120POS 0.05 GOLD PCB
PDF
/
Buying Options
Total Price: USD $93.87
Unit Price: USD $93.867098
≥1 USD $93.867098
≥196 USD $37.453098
≥504 USD $36.201905
≥994 USD $35.583529
Inventory: 3290
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Technical
Contact Finish - Post Tin
Contact Length - Post 0.075 1.91mm
Row Spacing - Mating 0.050 (1.27mm)
Insulation Color Black
Pitch - Mating 0.050 1.27mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.180 4.57mm
Terminal Pitch 1.27mm
Current Rating (Amps) 2.6A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
Additional Feature FOURRAY, TIGER EYE CONTACT
Number of Rows 4
Number of Positions 120
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Board Lock
JESD-609 Code e3
Series FOURRAY? FOLC
Published 2015
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 3 Weeks
