FLE-120-01-G-DV-TR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 40 POS 1.27mm Solder ST SMD T/R
PDF
/
Buying Options
Total Price: USD $5.76
Unit Price: USD $5.7552
≥1 USD $5.7552
≥10 USD $5.20784
≥100 USD $4.559544
Inventory: 912
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness - Post 3.00μin 0.076μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Plating Thickness 10μin
Length 25.51mm
Technical
Withdrawl Force-Min .417 N
Insertion Force-Max .417 N
Polarization Key POLARIZED HOUSING
Mating Contact Pitch 0.05 inch
Contact Resistance 15mOhm
Housing Color Black
Body Breadth 0.131 inch
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Row Spacing - Mating 0.050 (1.27mm)
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Pitch - Mating 0.050 1.27mm
Current Rating 1.75A
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.172 4.37mm
Depth 3.33mm
Orientation Straight
Total Number of Contacts 40
Current Rating (Amps) 2A per Contact
Contact Type Female Socket
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Additional Feature TAPE&REEL PKG
Number of Rows 2
Number of Positions 40
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series FLE
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Mounting Option 1 LOCKING
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
