FLE-119-01-G-DV
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
SAMTEC FLE-119-01-G-DV Board-To-Board Connector, FLE Series, 38 Contacts, Receptacle, 1.27 mm, Surface Mount, 2 Rows
PDF
/
Buying Options
Total Price: USD $6.2
Unit Price: USD $6.20296
≥1 USD $6.20296
≥10 USD $5.851851
≥100 USD $5.520613
≥500 USD $5.208118
≥1000 USD $4.913327
Inventory: 3171
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness - Post 3.00μin 0.076μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Plating Thickness 10μin
Width 3.33mm
Length 24.24mm
Technical
Withdrawl Force-Min .417 N
Insertion Force-Max .417 N
Durability 100 Cycles
PCB Contact Row Spacing 3.81 mm
Mating Contact Pitch 0.05 inch
Contact Resistance 15mOhm
Housing Color Black
Body Breadth 0.131 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Row Spacing - Mating 0.050 (1.27mm)
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Pitch - Mating 0.050 1.27mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.172 4.37mm
Depth 3.33mm
Orientation Straight
Total Number of Contacts 38
Current Rating (Amps) 2A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Additional Feature E.L.P., TIGER BEAM CONTACT
Number of Rows 2
Number of Positions 38
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series FLE
Published 2009
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Phosphor Bronze
