ESW-106-44-G-S-06

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description Rectangular Connector Female Socket
PDF
/
Inventory: 5633
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 3 Weeks

Physical

Contact Material Phosphor Bronze
Mounting Type Through Hole
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)

Technical

Operating Temperature -55°C~125°C
Packaging Tube
Series ESW
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type Elevated Socket
Number of Positions 6
Number of Rows 1
Gender Receptacle
Voltage - Rated 550VAC
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Type Forked
Current Rating (Amps) 5.2A per Contact
Insulation Height 0.735 18.67mm
Style Board to Board
Number of Positions Loaded 5
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Contact Length - Post 0.180 4.57mm
Contact Finish - Post Gold

Dimensions

Contact Finish Thickness - Mating 20.0μin 0.51μm
Contact Finish Thickness - Post 3.00μin 0.076μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
