ESW-101-12-G-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Elevated Socket SKT 1 POS Solder ST Thru-Hole
PDF
/
Inventory: 9824
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 3.00μin 0.076μm
Contact Finish Thickness - Mating 20.0μin 0.51μm
Length 3.05mm
Technical
Max Current Rating 6.9A
Max Voltage Rating (AC) 550V
Contact Resistance 10mOhm
Housing Color Black
Contact Finish - Post Gold
Number of Contacts 1
Contact Length - Post 0.090 2.29mm
Insulation Color Black
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.435 11.05mm
Depth 2.41mm
Orientation Straight
Current Rating (Amps) 5.2A per Contact
Contact Type Forked
Contact Finish - Mating Gold
Fastening Type Push-Pull
Voltage - Rated 550VAC
Gender Receptacle
Number of Rows 1
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 1
Connector Type Elevated Socket
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series ESW
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Polyester
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Contact Plating Gold
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
