ESQT-102-02-L-D-319-003
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
POLARIZED Rectangular Connector Header
PDF
/
Inventory: 3832
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Technical
Contact Gender FEMALE
Contact Finish - Post Tin
Contact Length - Post 0.531 13.50mm
Row Spacing - Mating 0.079 (2.00mm)
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded 3
Style Board to Board or Cable
Insulation Height 0.319 8.10mm
Current Rating (Amps) 4.5A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Forked
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
Additional Feature POLARIZED
Number of Rows 2
Number of Positions 4
Connector Type Elevated Socket
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series ESQT
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
