ESQ-120-12-S-D
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Elevated Socket SKT 40 POS 2.54mm Solder ST Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $10.69
Unit Price: USD $10.692
≥1 USD $10.692
≥10 USD $9.48024
≥100 USD $8.26496
≥500 USD $7.049522
≥1000 USD $6.466108
Inventory: 167
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 30.0μin 0.76μm
Plating Thickness 30μin
Length 51.31mm
Technical
Withdrawl Force-Min 1.39 N
Insertion Force-Max 1.668 N
Max Current Rating 6.9A
Max Voltage Rating (AC) 550V
Mating Contact Pitch 0.1 inch
Contact Resistance 10mOhm
Housing Color Black
Body Breadth 0.195 inch
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number Of PCB Rows 2
Contact Length - Post 0.090 2.29mm
Row Spacing - Mating 0.100 (2.54mm)
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.435 11.05mm
Depth 4.95mm
Orientation Straight
Current Rating (Amps) 5.7A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Forked
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Additional Feature TIGER BUY CONTACT
Voltage - Rated 550VAC
Gender Receptacle
Number of Rows 2
Number of Positions 40
Connector Type Elevated Socket
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series ESQ
Published 2000
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Housing Material Polyester
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
