ESQ-112-13-G-D
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
SAMTEC ESQ-112-13-G-D Board-To-Board Connector, Elevated, ESQ Series, 24 Contacts, Receptacle, 2.54 mm, Solder, 2 Rows
PDF
/
Buying Options
Total Price: USD $6.99
Unit Price: USD $6.985026
≥1 USD $6.985026
≥10 USD $6.589642
≥100 USD $6.216643
≥500 USD $5.864759
≥1000 USD $5.532798
Inventory: 4666
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 3.00μin 0.076μm
Contact Finish Thickness - Mating 20.0μin 0.51μm
Length 30.99mm
Technical
Insertion Force-Max 1.668 N
Polarization Key POLARIZED HOUSING
Max Current Rating 6.9A
Max Voltage Rating (AC) 550V
Mating Contact Pitch 0.1 inch
Contact Resistance 10mOhm
Body Breadth 0.195 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Contact Length - Post 0.290 7.37mm
Row Spacing - Mating 0.100 (2.54mm)
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.435 11.05mm
Depth 4.95mm
Orientation Straight
Current Rating (Amps) 5.7A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Forked
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Additional Feature TIGER BUY CONTACT
Voltage - Rated 550VAC
Gender Receptacle
Number of Rows 2
Number of Positions 24
Connector Type Elevated Socket
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series ESQ
Published 2012
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Mounting Option 1 LOCKING
Housing Material Polyester
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
