ESQ-103-69-S-T
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Female Socket
PDF
/
Inventory: 2562
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series ESQ
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type Elevated Socket
Number of Positions 9
Number of Rows 3
Gender Female
Voltage - Rated 550VAC
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
Contact Type Forked
Withdrawl Force-Min .7784 N
PCB Contact Row Spacing 2.54 mm
Mating Contact Pitch 0.1 inch
Contact Resistance 10mOhm
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number Of PCB Rows 3
Contact Length - Post 0.180 4.57mm
Row Spacing - Mating 0.100 (2.54mm)
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.735 18.67mm
Terminal Pitch 2.54mm
Current Rating (Amps) 5.7A per Contact
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Length - Termination 0.18 inch
Contact Finish Thickness - Mating 30.0μin 0.76μm
