ESQ-103-23-T-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
SAMTEC ESQ-103-23-T-S Board-To-Board Connector, Vertical, ESQ Series, 3 Contacts, Receptacle, 2.54 mm, Through Hole
PDF
/
Buying Options
Total Price: USD $0.93
Unit Price: USD $0.925355
≥1 USD $0.925355
≥10 USD $0.872976
≥100 USD $0.823562
≥500 USD $0.77694
≥1000 USD $0.732972
Inventory: 8493
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Housing Material Polyester
Mounting Option 1 LOCKING
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2011
Series ESQ
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Connector Type Elevated Socket
Number of Positions 3
Number of Rows 1
Gender Receptacle
Voltage - Rated 550VAC
Additional Feature TIGER BUY CONTACT
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Tin
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Forked
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 5.7A per Contact
Orientation Straight
Terminal Pitch 2.54mm
Depth 2.41mm
Insulation Height 0.535 13.60mm
Style Board to Board
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Contact Length - Post 0.190 4.83mm
Number Of PCB Rows 1
PCB Contact Pattern RECTANGULAR
Body Breadth 0.095 inch
Contact Resistance 10mOhm
Max Voltage Rating (AC) 550V
Max Current Rating 6.9A
Polarization Key POLARIZED HOUSING
Dimensions
Length 8.13mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
