CLT-115-03-L-D

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description Rectangular Connector Receptacle
PDF
/
Buying Options
Total Price: USD $16.2
Unit Price: USD $16.197247
≥1 USD $16.197247
≥209 USD $6.463407
≥494 USD $6.246778
≥1007 USD $6.140433
Inventory: 4428
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 3 Weeks

Physical

Contact Material Phosphor Bronze
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)

Technical

Operating Temperature -55°C~125°C
Packaging Tube
Series CLT
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type Receptacle
Number of Positions 30
Number of Rows 2
Gender Female
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Type Female Socket
Current Rating (Amps) 4.1A per Contact
Pitch 2mm
Insulation Height 0.083 2.10mm
Style Board to Board
Number of Positions Loaded All
Pitch - Mating 0.079 2.00mm
Insulation Color Black
Row Spacing - Mating 0.079 (2.00mm)
Contact Length - Post 0.116 2.95mm
Number of Contacts 30
Contact Finish - Post Tin

Dimensions

Contact Finish Thickness - Mating 10.0μin 0.25μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
