CLP-144-02-L-D-K-TR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Receptacle
PDF
/
Inventory: 7274
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Contact Plating Gold
Mounting Type Surface Mount
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series CLP
Feature Pick and Place
Part Status Active
Contact Finish - Post Tin
Number of Contacts 88
Row Spacing - Mating 0.050 (1.27mm)
Voltage - Rated AC 240V
Insulation Color Black
Pitch - Mating 0.050 1.27mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.084 2.14mm
Pitch 1.27mm
Current Rating (Amps) 3.3A per Contact
Contact Type Female Socket
Contact Finish - Mating Gold
Voltage - Rated DC 340V
Fastening Type Push-Pull
Voltage - Rated 240VAC 330VDC
Gender Female
Number of Rows 2
Number of Positions 88
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
