CLP-108-02-LTL-D-A-K-TR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
LOW PROFILE Rectangular Connector Female Socket
PDF
/
Inventory: 2380
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Plating Thickness 10μin
Technical
Insulator Color BLACK
Mating Contact Row Spacing 0.05 inch
Contact Pattern RECTANGULAR
Contact Finish Termination Tin (Sn) - with Nickel (Ni) barrier
Termination Type SURFACE MOUNT
Mating Contact Pitch 0.05 inch
Contact Style SQ PIN-SKT
Body Depth 0.09 inch
UL Flammability Code 94V-0
Contact Gender FEMALE
Body Breadth 0.12 inch
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Body Length or Diameter 0.417 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Terminal Pitch 1.27mm
Total Number of Contacts 16
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating GOLD (10) OVER NICKEL (50)
Subcategory Headers and Edge Type Connectors
Additional Feature LOW PROFILE
Number of Rows 2
Connector Type BOARD CONNECTOR
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Mounting Style STRAIGHT
Mounting Option 1 LOCKING
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Mounting Type BOARD
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 3 Weeks
