CLP-108-02-L-D-P-TR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 16 POS 1.27mm Solder ST SMD T/R
PDF
/
Buying Options
Total Price: USD $3.24
Unit Price: USD $3.2384
≥1 USD $3.2384
≥10 USD $2.93832
≥100 USD $2.589136
≥500 USD $2.200739
Inventory: 1891
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Length 10.59mm
Technical
Contact Resistance 10mOhm
Housing Color Black
Contact Finish - Post Tin
Number of Contacts 16
Row Spacing - Mating 0.050 (1.27mm)
Voltage - Rated AC 240V
Insulation Color Black
Pitch - Mating 0.050 1.27mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.084 2.14mm
Depth 3.05mm
Orientation Straight
Pitch 1.27mm
Current Rating (Amps) 3.3A per Contact
Contact Type Female Socket
Contact Finish - Mating Gold
Voltage - Rated DC 340V
Fastening Type Push-Pull
Voltage - Rated 240VAC 330VDC
Gender Female
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 16
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Pick and Place
Series CLP
Published 2015
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Contact Plating Gold
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 6 Weeks
