CLH-135-F-D-DV-P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
PICK AND PLACE PAD Rectangular Connector Header
PDF
/
Inventory: 5264
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material PHOSPHOR BRONZE
Contact Plating Gold
Mounting Type BOARD
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Mounting Style STRAIGHT
Technical
Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type BOARD CONNECTOR
Number of Rows 2
Gender Female
Additional Feature PICK AND PLACE PAD
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 3.5 inch
Number Of PCB Rows 2
Number of Contacts 70
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Min) -65°C
Body Depth 0.14 inch
Rated Current (Signal) 1.5A
Contact Style SQ PIN-SKT
Insulator Color BLACK
Mating Contact Row Spacing 0.1 inch
Contact Pattern RECTANGULAR
Body/Shell Style SOCKET
Contact Resistance 10mOhm
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Plating Thickness FLASH inch
