CLE-170-01-G-DV-A-TR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 140 POS 0.8mm Solder ST SMD T/R
PDF
/
Inventory: 2564
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Surface Mount
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Board Mounting Option POSITIONING PIN
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series CLE
JESD-609 Code e4
Feature Board Guide
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Withdrawl Force-Min .3336 N
Insertion Force-Max .556 N
Dielectric Withstanding Voltage 375VAC V
Polarization Key POLARIZED HOUSING
Mating Contact Pitch 0.031 inch
Insulation Resistance 5000000000Ohm
Contact Resistance 15mOhm
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Row Spacing - Mating 0.047 (1.20mm)
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.031 0.80mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.130 3.30mm
Terminal Pitch 0.7874mm
Total Number of Contacts 140
Current Rating (Amps) 2.7A per Contact
Contact Type Female Socket
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Additional Feature TAPE & REEL PACKAGING
Gender Female
Number of Rows 2
Number of Positions 140
Connector Type Receptacle, Pass Through
ECCN Code EAR99
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 10.0μin 0.25μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Plating Thickness 10μin
