BSW-112-04-L-M
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
TIGER BUY CONTACT; LOW PROFILE Rectangular Connector Receptacle
PDF
/
Inventory: 2973
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Terminal Pitch 2.54mm
Insulation Height 0.350 8.89mm
Style Board to Board
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Contact Length - Post 0.125 3.18mm
Contact Finish - Post Tin
UL Flammability Code 94V-0
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
Additional Feature TIGER BUY CONTACT; LOW PROFILE
Gender Female
Number of Rows 1
Number of Positions 12
Connector Type Receptacle, Breakaway
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series BSW
Packaging Bulk
Operating Temperature -55°C~125°C
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
Physical
Insulation Material Polyethylene Terephthalate (PET), Glass Filled
Contact Shape Square
Mounting Type Through Hole, Bottom Mount
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
