BSW-104-04-S-E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
BOARD STANDOFFS Rectangular Connector Receptacle
PDF
/
Inventory: 5211
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 30.0μin 0.76μm
Plating Thickness 30μin
Technical
Insulation Resistance 5000000000Ohm
Rated Current (Signal) 1A
Body Breadth 0.27 inch
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number Of PCB Rows 1
Contact Length - Post 0.100 2.54mm
Reliability COMMERCIAL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.350 8.89mm
Contact Type Female Socket
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Additional Feature BOARD STANDOFFS
Gender Female
Number of Rows 1
Number of Positions 4
Connector Type Receptacle, Breakaway
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code yes
Series BSW
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Insulation Material Polyethylene Terephthalate (PET), Glass Filled
Contact Shape Square
Mounting Type Through Hole, Bottom Mount
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
