BSW-102-04-T-S-S
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Bottom Mount Socket Strip SKT 2 POS 2.54mm Solder ST Thru-Hole Bulk
PDF
/
Inventory: 2339
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Contact Material Bronze
Contact Plating Tin
Mounting Type BOARD
Housing Material Thermoplastic
Mounting Option 1 LOCKING
Technical
Published 2014
JESD-609 Code e3
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type BOARD CONNECTOR
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Number of Rows 1
Gender Female
Additional Feature TIGER BUY CONTACT; LOW PROFILE
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Straight
Depth 5.08mm
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 1
Number of Contacts 2
PCB Contact Pattern RECTANGULAR
UL Flammability Code 94V-0
Housing Color Black
Contact Style SQ PIN-SKT
Contact Resistance 10mOhm
Insulation Resistance 5000000000Ohm
Body/Shell Style SOCKET
Polarization Key POLARIZED HOUSING
Contact Pattern RECTANGULAR
Current Rating (Max) 3A
Dimensions
Length 5.59mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
