BCS-112-L-D-PE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RCPT 24POS 0.1 GOLD PCB
PDF
/
Buying Options
Total Price: USD $4.2
Unit Price: USD $4.204239
≥1 USD $4.204239
≥10 USD $3.966265
≥100 USD $3.741761
≥500 USD $3.529959
≥1000 USD $3.330149
Inventory: 4804
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 50.0μin 1.27μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Plating Thickness 10μin
Width 5.08mm
Length 30.48mm
Technical
Withdrawl Force-Min .834 N
Insertion Force-Max 1.39 N
Durability 500 Cycles
Dielectric Withstanding Voltage 375VAC V
Max Current Rating 5.9A
Max Voltage Rating (AC) 475V
Mating Contact Pitch 0.1 inch
Insulation Resistance 5000000000Ohm
Contact Resistance 10mOhm
Housing Color Black
UL Flammability Code 94V-0
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number Of PCB Rows 2
Contact Length - Post 0.128 3.25mm
Row Spacing - Mating 0.100 (2.54mm)
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.290 7.37mm
Depth 7.62mm
Orientation Vertical
Current Rating (Amps) 4.6A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Additional Feature ELP, PASS THROUGH ENTRY
Voltage - Rated 475VAC
Gender Receptacle
Number of Rows 2
Number of Positions 24
Connector Type Receptacle, Pass Through
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Tiger Claw? BCS
Published 2009
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP), Glass Filled
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
