801-83-015-10-001101

Preci-Dip
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description Conn DIP Socket SKT 15 POS 2.54mm Solder ST Thru-Hole T/R
PDF
/
Inventory: 5590
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Mating 29.5μin 0.75μm
Length 38.1mm

Technical

Insulation Resistance 10GOhm
Contact Resistance 10mOhm
UL Flammability Code 94V-0
Contact Finish - Post Tin
Contact Length - Post 0.118 3.00mm
Voltage - Rated AC 100V
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Current Rating 1A
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.276 7.00mm
Depth 2.54mm
Orientation Straight
Current Rating (Amps) 3A
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Voltage - Rated DC 150V
Fastening Type Push-Pull
Gender Female
Number of Rows 1
Number of Positions 15
Connector Type Socket
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 801
Published 2012
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Insulation Material Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Contact Shape Circular
Mounting Type Through Hole
Mount Through Hole
Contact Material Beryllium Copper

Supply Chain

Factory Lead Time 10 Weeks
