90148-1206
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings 2.54MM SR RA BD CONN 6P AU
PDF
/
Buying Options
Total Price: USD $2.3
Unit Price: USD $2.300462
≥1 USD $2.300462
≥10 USD $2.170246
≥100 USD $2.047407
≥500 USD $1.93151
≥1000 USD $1.822182
Inventory: 8663
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 8.5mm
Length 15.2mm
Height 3.3mm
Technical
Glow Wire Compliant Non-compliant
Insertion Force-Max .973 N
Contact Pattern RECTANGULAR
Max Voltage Rating (AC) 350V
Number of Circuits 5
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number of Contacts 6
Number Of PCB Rows 2
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 3A
Orientation Right Angle
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature C-GRID III
Voltage - Rated 350V
Gender Receptacle
Number of Rows 1
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Solder
Pbfree Code yes
Physical
Housing Material Polyester
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
