90148-1110
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RECEPT HORIZ 10POS .100 PCB
PDF
/
Buying Options
Total Price: USD $4.27
Unit Price: USD $4.271418
≥1 USD $4.271418
≥10 USD $4.029643
≥100 USD $3.801547
≥500 USD $3.586367
≥1000 USD $3.383361
Inventory: 5934
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Bronze
Contact Plating Tin
Mount Through Hole
Housing Material Polyester
Technical
Published 2004
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Receptacle, Socket
Number of Positions 10
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 1
Voltage - Rated 350V
Additional Feature C-GRID III
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 10
Orientation Right Angle
Depth 8.5mm
Current Rating 3A
Number of Conductors ONE
Reference Standard UL, CSA
Voltage - Rated AC 350V
Reliability COMMERCIAL
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Contact Gender Female
UL Flammability Code 94V-0
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
ELV Compliant
Max Voltage Rating (AC) 350V
Dielectric Withstanding Voltage 350VAC V
PCB Contact Row Spacing 7.62 mm
Contact Pattern RECTANGULAR
Insertion Force-Max 2.9468 N
Glow Wire Compliant Non-compliant
Dimensions
Length 25.4mm
Width 8.5mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
