87368-2220
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RECEPT 22POS 2MM SMD GOLD
PDF
/
Inventory: 8629
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 15μin
Width 5mm
Length 22.2mm
Height 4.9mm
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 500VAC V
Max Voltage Rating (AC) 125V
Insulation Resistance 1000000000Ohm
Contact Resistance 15mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 1A
Body Depth 0.197 inch
UL Flammability Code 94V-0
Body Breadth 0.193 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Lead Pitch 2mm
Number Of PCB Rows 2
Row Spacing - Mating 2.0066 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Reach Compliance Code unknown
Orientation Right Angle
Total Number of Contacts 22
Pitch 2.0066mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature MILLI-GRID, SIDE ENTRY
Gender Female
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 22
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Solder
Part Status Discontinued
Published 2005
Physical
Housing Material Nylon
Mount Surface Mount
Contact Plating Gold
Contact Material Bronze
