79107-7002

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description CONN RECEPT 2MM 6POS VERT
PDF
/
Buying Options
Total Price: USD $1.56
Unit Price: USD $1.563532
≥1 USD $1.563532
≥10 USD $1.475035
≥100 USD $1.391538
≥500 USD $1.312774
≥1000 USD $1.238472
Inventory: 3995
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 13 Weeks

Physical

Contact Material Bronze
Contact Plating Gold
Mount Through Hole
Housing Material Thermoplastic

Technical

Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
Connector Type Receptacle, Socket
Number of Positions 6
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Gender Receptacle
Voltage - Rated 125V
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2mm
Total Number of Contacts 6
Orientation Vertical
Current Rating 1A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Row Spacing - Mating 2.0066 mm
Number Of PCB Rows 2
Lead Pitch 2mm
PCB Contact Pattern RECTANGULAR
Contact Gender Female
Body Depth 0.175 inch
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Contact Resistance 25mOhm
Insulation Resistance 1000000000Ohm
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 500VAC V
Durability 50 Cycles
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant

Dimensions

Plating Thickness 15μin
Length - Termination 0.118 inch

Compliance

Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
