52365-1491
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
NONE Rectangular Connector Female Socket
PDF
/
Inventory: 2565
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Tin
Mount Surface Mount
Housing Material Nylon
Technical
Packaging Tape & Reel (TR)
Termination Solder
Connector Type Receptacle
Number of Rows 2
Gender Female
Additional Feature NONE
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating SN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 990.6μm
Reach Compliance Code unknown
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Row Spacing - Mating 1.4478 mm
Number Of PCB Rows 2
Number of Contacts 14
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Body Breadth 0.138 inch
Operating Temperature (Min) -40°C
UL Flammability Code 94V-0
Body Depth 0.157 inch
Rated Current (Signal) 0.5A
Contact Style SQ PIN-SKT
Insulation Resistance 100000000Ohm
Polarization Key D-SHAPE
Dielectric Withstanding Voltage 500VAC V
PCB Contact Row Spacing 3.81 mm
Contact Pattern RECTANGULAR
Dimensions
Height 4mm
Length 10.7mm
Width 3.15mm
Compliance
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
