5031590810
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RCPT 8POS 0.059 TIN PCB
PDF
/
Buying Options
Total Price: USD $0.73
Unit Price: USD $0.7304
≥1 USD $0.7304
≥10 USD $0.60456
≥100 USD $0.503747
≥500 USD $0.403022
≥1000 USD $0.352642
≥3000 USD $0.335007
Inventory: 4799
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 39.4μin 1.00μm
Contact Finish Thickness - Mating 39.4μin 1.00μm
Plating Thickness 39μin
Technical
Durability 30 Cycles
PCB Contact Row Spacing 2.0066 mm
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Mating Contact Pitch 0.059 inch
Insulation Resistance 500000000Ohm
Contact Resistance 20mOhm
Rated Current (Signal) 2A
Contact Gender FEMALE
PCB Contact Pattern STAGGERED
Number Of PCB Rows 2
Contact Length - Post 0.134 3.40mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Beige
Pitch - Mating 0.059 1.50mm
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.313 7.95mm
Mixed Contacts NO
Contact Type Forked
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Tin
Subcategory Headers and Edge Type Connectors
Fastening Type Latch Holder
Additional Feature CLIK-MATE, POLARIZED
Number of Rows 1
Applications Automotive, General Purpose, Industrial, Lighting, Medical
Number of Positions 8
Connector Type Receptacle
Termination Kinked Pin, Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Series CLIK-Mate 503159
Published 2011
Packaging Tray
Operating Temperature -40°C~105°C
Physical
Mounting Option 1 LOCKING
Insulation Material Polyamide (PA), Nylon
Mounting Type Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 10 Weeks
