5023820371
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RCPT 3POS 0.049 GOLD SMD
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8272
≥1 USD $0.8272
≥10 USD $0.68376
≥100 USD $0.569536
Inventory: 12253
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 39.4μin 1.00μm
Contact Finish Thickness - Mating 3.90μin 0.099μm
Technical
Polarization Key POLARIZED HOUSING
Mating Contact Pitch 0.049 inch
Contact Gender FEMALE
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number Of PCB Rows 1
Body Length or Diameter 0.28 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Insulation Color Natural
Pitch - Mating 0.049 1.25mm
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.173 4.40mm
Total Number of Contacts 3
Current Rating (Amps) 1A
Contact Type Forked
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Latch Holder
Additional Feature EMBOSSED TAPE PACKAGING
Voltage - Rated 50V
Number of Rows 1
Applications Automotive, General Purpose, Industrial, Lighting, Medical
Number of Positions 3
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Solder Retention
JESD-609 Code e4
Series CLIK-Mate 502382
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Mounting Option 1 LOCKING
Insulation Material Resin
Mounting Type Surface Mount
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 20 Weeks
