44769-1601
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN HDR RCPT 16POS VERT TIN PCB
PDF
/
Buying Options
Total Price: USD $5.39
Unit Price: USD $5.391649
≥1 USD $5.391649
≥10 USD $5.086466
≥100 USD $4.798549
≥500 USD $4.526932
≥1000 USD $4.270698
Inventory: 3870
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.134 inch
Plating Thickness 100μin
Technical
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Withdrawl Force-Min 3.614 N
Insertion Force-Max 11.5648 N
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 250.25kV
Durability 30 Cycles
Dielectric Withstanding Voltage 1500VAC V
Polarization Key POLARIZED HOUSING
Insulation Resistance 1000000000Ohm
Contact Resistance 100mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 5A
Body Depth 0.535 inch
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender Female
Body Breadth 0.331 inch
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Row Spacing - Mating 2.9972 mm
Body Length or Diameter 1.181 inch
Reliability COMMERCIAL
Reference Standard UL,CSA,TUV
Number of Conductors ONE
Current Rating 5A
Orientation Vertical
Total Number of Contacts 16
Pitch 3mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Voltage - Rated 250V
Gender Receptacle
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 16
Connector Type Receptacle, Socket
Termination Solder
Pbfree Code yes
Physical
Housing Material Polymer
Shell Material GLASS FILLED POLYAMIDE
Mount Through Hole
Contact Plating Tin
Contact Material Brass
