44769-0802
RoHS
/
Package 0802
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN HDR RCPT 8POS 3MM VERT PCB
PDF
/
Buying Options
Total Price: USD $3.24
Unit Price: USD $3.23659
≥1 USD $3.23659
≥10 USD $3.053388
≥100 USD $2.880551
≥500 USD $2.717505
≥1000 USD $2.56368
Inventory: 3967
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length - Termination 0.134 inch
Plating Thickness 15μin
Technical
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Withdrawl Force-Min 3.614 N
Contact Pattern RECTANGULAR
Durability 30 Cycles
Dielectric Withstanding Voltage 1500VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 250V
Insulation Resistance 1000000000Ohm
Contact Resistance 100mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 5A
Body Depth 0.535 inch
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender Female
Body Breadth 0.331 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Row Spacing - Mating 2.9972 mm
Body Length or Diameter 0.709 inch
Reliability COMMERCIAL
Reference Standard UL,CSA,TUV
Number of Conductors ONE
Current Rating 5A
Orientation Vertical
Total Number of Contacts 8
Pitch 3mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Voltage - Rated 250V
Gender Receptacle
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 8
Connector Type Header, Receptacle, Socket
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2011
Physical
Housing Material Polymer
Shell Material GLASS FILLED POLYAMIDE
Package / Case 0802
Mount Through Hole
Contact Plating Gold
Contact Material Brass
Supply Chain
Factory Lead Time 11 Weeks
