44769-0601
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RCPT 6POS 0.118 TIN PCB
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.362254
≥1 USD $1.362254
≥10 USD $1.285144
≥100 USD $1.2124
≥500 USD $1.143777
≥1000 USD $1.079032
Inventory: 1359
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Housing Material Polyamide
Technical
Published 2007
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
Connector Type Receptacle, Socket
Number of Positions 6
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Black
Number of Rows 2
Gender Receptacle
Voltage - Rated 250V
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3mm
Total Number of Contacts 6
Orientation Vertical
Current Rating 5A
Number of Conductors ONE
Reference Standard UL,CSA,TUV
Reliability COMMERCIAL
Body Length or Diameter 0.591 inch
Row Spacing - Mating 2.9972 mm
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Body Breadth 0.331 inch
UL Flammability Code 94V-0
Empty Shell NO
Body Depth 0.535 inch
Rated Current (Signal) 5A
Contact Style SQ PIN-SKT
Contact Resistance 100mOhm
Insulation Resistance 1000000000Ohm
Max Voltage Rating (AC) 250V
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 1500VAC V
Durability 30 Cycles
Contact Pattern RECTANGULAR
Halogen Free Low Halogen
Glow Wire Compliant Non-compliant
Dimensions
Plating Thickness 100μin
Length - Termination 0.134 inch
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Contains Lead
