22-17-3102
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RECEPT 10POS .100 VERT PCB
PDF
/
Buying Options
Total Price: USD $1.53
Unit Price: USD $1.5295
≥1 USD $1.5295
≥10 USD $1.25495
≥100 USD $1.216
≥500 USD $1.1761
≥1000 USD $1.13715
Inventory: 52
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Brass
Contact Plating Gold
Mount Through Hole
Housing Material Nylon
Technical
Packaging Bulk
Published 2009
Pbfree Code yes
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Receptacle, Socket
Number of Positions 10
Max Operating Temperature 75°C
Min Operating Temperature 0°C
Color Natural, White
Number of Rows 1
Gender Receptacle
Voltage - Rated 250V
Additional Feature BOTTOM ENTRY
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 10
Orientation Straight
Depth 7.7mm
Current Rating 2.5A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Number Of PCB Rows 1
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Female
UL Flammability Code 94V-0
Housing Color White
Contact Style BELLOWED TYPE
Contact Resistance 20mOhm
Insulation Resistance 500000000000Ohm
Body/Shell Style PLUG
Dielectric Withstanding Voltage 250VAC V
Durability 25 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max 2.502 N
Withdrawl Force-Min .834 N
Halogen Free Low Halogen
Glow Wire Compliant Non-compliant
Dimensions
Height 7.9mm
Length 25.3mm
Width 4.7mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
