22-15-2146
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings KK 100 PCB Assy RtAn 14 Ckt Tin
PDF
/
Inventory: 4184
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Withdrawl Force-Min .556 N
Insertion Force-Max 2.502 N
Contact Pattern RECTANGULAR
Durability 25 Cycles
Body/Shell Style PLUG
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Contact Gender FEMALE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 2.5A
Orientation Right Angle
Total Number of Contacts 14
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature POLARIZED
Voltage - Rated 250V
Number of Rows 1
Color White
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Number of Positions 14
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Solder
Pbfree Code yes
Physical
Housing Material Nylon
Mount Through Hole
Contact Plating Tin
Contact Material Brass
