22-14-2034
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RECEPT 3POS .100 VERT PCB
PDF
/
Inventory: 976
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Contact Resistance 20mOhm
UL Flammability Code 94V-0
Contact Gender Female
Current Rating 2.5A
Orientation Straight
Total Number of Contacts 3
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature BOTTOM ENTRY
Voltage - Rated 250V
Gender Receptacle
Number of Rows 1
Color White
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Number of Positions 3
Connector Type Receptacle, Socket
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2011
Physical
Housing Material Nylon
Mount Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 8 Weeks
