RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
TOP ENTRY Rectangular Connector Receptacle
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.429496
≥1 USD $0.429496
≥10 USD $0.405186
≥100 USD $0.382246
≥500 USD $0.360611
≥1000 USD $0.3402
Inventory: 2664
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 10.06mm
Technical
Insertion Force-Max 2.502 N
Contact Pattern RECTANGULAR
Durability 25 Cycles
Dielectric Withstanding Voltage 250VAC V
Number of Circuits 3
Body/Shell Style PLUG
Insulation Resistance 500000000000Ohm
Contact Resistance 20mOhm
Contact Style BELLOWED TYPE
PCB Contact Pattern RECTANGULAR
Number of Contacts 4
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 2.5A
Depth 7.7mm
Orientation Vertical
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature TOP ENTRY
Gender Receptacle
Number of Rows 1
Color White
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
Published 2009
Physical
Board Mounting Option PCB EDGE LOCKING HOOK
Mounting Style STRAIGHT
Housing Material Nylon
Mounting Type BOARD
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 8 Weeks
Alternative Model
